Kenworth T800 Hot Oil Unit White
Hot Oil Units
White 2013 Kenworth T800 Hot Oil Unit with a 7M BTU LPG heater and Gardner Denver 6,000 PSI pump. Features a 75 BBL tank and Murphy control panel for thermal well operations.
Key specifications
Feature
Specification
Chassis Make/Model
Kenworth T800 (Year 2013)
Heater Type
LPG Gas
Engine
Cummins (Series: 79616513)
Triplex Pump
Gardner Denver Model TEE
Max Pressure
LPG Gas
Heating Capacity
Input: 7 Million BTU / Output: 5.8 Million BTU
Tank Capacity
62.9 BBL (Detailed) / 75 BBL (Nominal)
Auxiliary Pumps
Equipped with a Viking LV-3900 and a Bowie 3300 pump.
Heating Coil
2" diameter coil inside an A-36 Steel (3/16") furnace.
Control Panel
Murphy Electrical Panel
Usage Instructions
- Mobility: The unit is mounted on a 2013 Kenworth T800 truck chassis, colored white, allowing for highway and field transport.
- Heating Operations: Operates using an LPG-fired heater with a 2-inch coil system.
- Pressure Limits: The high-pressure system is rated for fluid discharge up to 6,000 PSI.
Applications
- Primary Function: Hot Oil Unit.
- Industry Use: Designed for oilfield thermal operations, typically including the heating of fluids for well injection, paraffin removal (dewaxing), and high-pressure pumping services.
